Sol-Ark Solar Generator

AEC Solar
Fortress & Sol-Ark
Energy Storage Solutions

Innovative, affordable and easy-to-install energy storage solution (ESS) that can used for both new and existing PV arrays. Fortress Power ESS uses the innovative Sol-Ark inverter, which is designed and engineered in the U.S.

WORLD’S MOST EFFICIENT

93% round-trip efficiency rate (PV-> battery-> AC load), 8- 20% higher than the competitors’

POWERFUL

9.6 KW continuous for On-Grid production; 8KW continuous for OFf-Grid production & 20kW peak Off Grid for starting 3 ton A/C or well pumps; 18.5 KWH storage capacity per unit and is scalable to 222kWH

FLEXIBLE

It can be DC coupled to new array, as well as AC coupled to existing array. DC + AC Coupling Combined supports up-to 13KW PV array

SIMPLE TO INSTALL AND USE

The plug and play solution integrate charger, inverter, auto-transfer, distribution box, monitoring all in one unit

SCALABLE

The 12 KW hybrid inverter can be stacked-up to 9 units for a total Power Output of 108KW; 18.5 KWH Storage Capacity per unit and is scalable to 222kWH. It supports both residential (120/240V) and commercial (120/208V) application.

HIGHEST SAFETY

Safe Lithium Iron Phosphate chemistry; no cooling and ventilation is required

Sol-Ark Solar Generator
Percent Icon

Next Generation Efficiency

3X Better! Only 3.5% losses vs. 14% in today’s battery based systems

Plug Icon

Split Phase & Three Phase

Sol-Ark’s 12K pumps out power just like the grid, allowing you to power 120V/ 240V/208V appliances

Power Icon

Grid-Tied, Hybrid, Off-Grid

Manages power from Solar, Battery, Grid, Load, and Generator simultaneously

Arrow Icon

Flexible

Sol-Ark is expandable from 5 to 52 (16.5 kW) solar panels and 0-32 batteries. Per 12K unit.

Shield Icon

10-Year Standard Warranty

No need for additional warranties. The 12K comes standard 10-year warranty right out of the box.

SPECIFICATIONS

General
Dimensions (H x W x D)
28.0″ x 17.375″ x 9.37″
Weight
77 lbs.
Enclosure
NEMA type 1 (Indoor Use)
Ambient Temperature (3 variable speed fans)
-25 to 55°C, >45°C derating
Display
Color touch screen
Wi-Fi Communication (monitoring or SW updates)
Included
Snap on sensors for limited selling to household
Included
Standard Warranty (verified by HALT testing)
10 Years
Solar
Max allowed PV Power
16,500W
Max PV Power delivered to battery and AC outlets
12,000W
Max DC Voltage
500V
MPPT Voltage Range
150-425V
Starting Voltage
175V
Number of MPPT
2
Solar Strings per MPPT
2
Max DC Current per MPPT
18A @ 400V
Max AC Coupled Input (Micro/String Inverters)
9,600W
Max Combined Solar Input (DC+AC)
13,000W
AC Output
Connections
120/240/208V split phase
Continuous AC power on Solar or Battery
9,600W 40A L-L (240V)
4,800W 40A L-N (120V)
Surge AC power 5sec
20,000VA L-L (240V)
10,000VA L-N (120V)
Frequency
60/50Hz
Continuous AC power with Grid or Generator
12,000W 50A L-L (240V)
6,000W 50A L-N (120V)
CEC Efficiency
96.0% (Peak 97.0%)
Response Time (Grid-Tied to Off-Grid)
4ms
Protection & Certifications
Grid Sell Back – UL1741-2010/2018, IEEE1547a-2003/2014, FCC 15 class B, (April 2019: UL1741SA, CA Rule 21, HECO Rule 14H)
Yes
Sol-Ark and Fortress Systems
